Name: Ruck S-Prime 12″ | 1692 CFM Inline Fan
Brand: Ruck
SKU: 147518
Availability: InStock
Rating: 5.00 (1 reviews)

Ruck S-Prime 12″ | 1692 CFM Inline Fan

Rated 5.00 out of 5 based on 1 customer rating

(1 customer review)

$ 492.95

Ruck S-Prime fans offer great efficiency rates with the added benefit of sound insulation surrounding the fan. Manufactured in Germany, S-Prime fans are built with powerful motors in a strong galvanized steel housing. Their compact design makes them great for commercial, industrial and residential venting applications.

Sound insulated casing for quiet operation
Incorporated Prime mixed flow fan
Very high efficiency rates
One-phase AC motor
Galvanized sheet steel casing
5.5 foot power cord
3 year warranty
Hanging tabs for additional isolation
Made in Germany
FOR USE WITH AIR BOX 4+

Bundle and Save! See "Frequently Bought Together" items below ⬇

Description

Specifications

Voltage U_N	120 V 1~
Current I_max	4.7 A
Ambient temperature t_A	40 °C
Conveyed medium temperature t_M	40 °C
Speed Control	V
Motor protection	TMI
Insulation class motor	F
Weight	15,2 kg
Number of poles	2
IP motor	IP00
IP terminal box	–
Min. operating temperature	-25 °C

Connection data entire unit
Rated frequency	Hz	60
Rated voltage	V	120
Rated power	W	517
Max. operating current	A	4.7
Phase		1~
Motor Type		1~
Type of motor control		V
Motor protection		TMI
Capacitor µ	µF	20
Capacitor voltage	V	250
Insulation class motor		F
Number of poles		2
IP motor		IP00
IP terminal box		–
IP complete unit		–
Min. operating temperature	°C	-25

Additional information

Weight	15.2 kg
CFM Rating:	1692
Max RPM:	3380
Voltage:	120V
Max Amps A:	4.7
Static Pressure	700

Reviews (1)

1 review for Ruck S-Prime 12″ | 1692 CFM Inline Fan

Todd B. (verified owner) – February 2, 2023

Rated 5 out of 5
We installed an Ruck S-Prime 12″ Inline Fan on an exhaust system for a laser cutter/engraver. It was paired with a Air Box 4+ Carbon Filter, which I have reviewed separately. The exhaust system was partially installed during the build-out of an in-house model shop at an architectural firm. Basically, the duct was installed for a portion of the run but fan, filter, and machine connections were not provided. The configuration of the existing ducting was long, convoluted, and undersized. We were concerned about the capability of the system to provide the airflow we were after. Our solution was to increase the duct size over the last section of the system, and install an oversized fan and filter at the end. We were attracted to the Ruck S-Prime Fan for it’s specifications and simple elegant design. While not made in the USA, the fan’s German origin supported our opinion that it was of high quality. The fan and filter have now been installed and we are very pleased with the air flow provided. More impressive is the quietness of the fan when in operation. It is no problem to have a normal conversation when standing directly under the fan. Our dust collector is significantly louder even though it is located in a separate room. An excellent product.

Add a review

Shipping & Delivery

Shiping Note:

Dear Customers,

Please be advised that for deliveries to Alaska, Hawaii, and Puerto Rico, a delivery surcharge may apply. We will notify you of any additional charges before your order ships.

Order processing can take from 3 to 5 business days for Air Box filter units, inline fans, and replacement filters, and up to 4 weeks for custom-built orders. We prioritize orders for essential services such as schools, government and the healthcare industry.

We charge a flat shipping rate on the date of your order.

Please note that freight quotes may vary on the shipment date due to fluctuating fuel prices, brokerage fees, and/or special handling requirements. We do all we can to ship your orders promptly and at the lowest freight cost possible.

Note: Air Box 4 and Air Box 4+ filter units are stacked high on skids for shipping to ensure their protection and prevent any damage during transit.
Additionally, bundles, which include Air Box units and inline fans, may ship from different locations. As a result, one product may arrive before the other.

Thank you for your understanding and continued support

For Air Box shipping policy go here

How to calculate CFM

To calculate the CFM (cubic feet per minute) you need for a room, you can use the following formula:

CFM = (room volume number of air changes per hour) / 60*

Room volume is the cubic footage of the room. To calculate this, multiply the length, width, and height of the room.

Number of air changes per hour is the number of times you want the air in the room to be replaced in an hour. (A good rule of thumb is to aim for 2-3 air changes per hour).

60 is the number of minutes in an hour.

For example:

If a room is 10 feet long, 12 feet wide, and 8 feet high, the room volume would be 960 cubic feet. If you want the air in the room to be replaced 2 times per hour, you would need a fan with a CFM rating of 320.

CFM = (960 cubic feet * 2 air changes per hour) / 60 minutes per hour = 320 cubic feet per minute

It is important to note that this is a general formula. The actual CFM requirements to ventilate a room may vary depending on a number of factors, such as the number of people in the room, the activities taking place in the room, and the type of ventilation system in the room. If you are unsure how many CFM you need, it is always best to consult with a professional.

Here are some additional factors to consider when calculating CFM requirements:

The number of people in the room. The more people in the room, the more CFM you will need to remove the stale air and replace it with fresh air.
The activities taking place in the room. Activities that generate heat, such as cooking or exercising, will require more CFM to remove the hot air and replace it with cooler air.
The type of ventilation system in the room. If the room has a natural ventilation system, such as open windows or doors, you will need less CFM than if the room has a mechanical ventilation system, such as an air conditioner or furnace.
Type of filter being used. CARBON filters and HEPA filters have different CFM requirements, make sure you check the specs closely

By considering all of these factors, you can determine the correct CFM requirements for your room and ensure that you have the proper ventilation to keep the air fresh, healthy and clean.
