Specifications
6″ S-Prime Evo | 60 Hz | |
Voltage UN | 120 V 1~ |
Current Imax | 1 A |
Ambient temperature tA | 40 °C |
Conveyed medium temperature tM | 40 °C |
Speed Control | 0-10V |
Motor protection | TEC |
Insulation class motor | F |
Weight | 7,7 kg |
Number of poles | 2 |
IP motor | IP54 |
IP terminal box | IP44 |
Min. operating temperature | -230 °C |
Connection data entire unit
Rated frequency | Hz | 60 |
Rated voltage | V | 120 |
Rated power | W | 72 |
Max. operating current | A | 1 |
Phase | 1~ | |
Motor Type | EC | |
Type of motor control | 0-10V | |
Motor protection | TEC | |
Capacitor µ | µF | – |
Capacitor voltage | V | – |
Insulation class motor | F | |
Number of poles | ||
IP motor | IP54 | |
IP terminal box | IP44 | |
IP complete unit | IPX4 | |
Min. operating temperature | °C | -30 |
